D2405-S12-08GP-SS

Connection Details	Side 1 Connection Type: DIN Tube Side 1 Tube OD: 12mm Side 1 Thread Type: M20X1.5 Side 1 Standard: DIN 2353, ISO 8434-1 Side 1 Role: Tube Connection Side 1 DIN Pressure Series: Heavy Side 2 Connection Type: Female NPT Direct Gauge Port Side 2 Pipe Size: 1/2" Side 2 Standard: ISO 1179 Side 2 Role: Port Connection
Body & Materials	Shape: Straight Shape Type: Female Connector Primary Material: Stainless Steel Material Grade: 316Ti (1.4571)
Dimensions	Hex/Wrench: 27mm Weight: 0.32 lb
Performance Specifications	Working Pressure: 9137 psi Temperature Range: -425°F to 1200°F Burst Pressure: 36548 psi Burst Ratio: 4:1
Cross References	Parker TFD Part Number: MAV12S1/2NPT71
Regulatory & Compliance	RoHS Compliance: Compliant REACH Compliance: No Substance(s) Present Above Threshold
Series Configuration	DIN Tube x Female Pipe
Technical Series Configuration	DIN 2353/ISO 8434-1 Flareless Tube x SAE J476 Female NPTF Connector
Side 1 Connection Type	DIN Tube
Side 2 Connection Type	Female NPT Direct Gauge Port
Shape	Straight
Product Type	Fittings
