Flange Plugs / 1824-12

1824-12

1824-12
1824-12 - Image 2
1824-12 - Image 3
1824-12 - Image 4
1824-12 - Image 5
Product Code: 1824-12 Brand:
Options
1824-08 1824-12 1824-16 1824-16-ss 1824-20 1824-20-ss 1824-24 1824-32
- +

Description

Steel, SAE J518 Code 62 Split Flange Plug, 3/4″ Flange Plug

Additional information

Connection Details

Connection Type: Flange Plug
Flange Size: 3/4"
Standard: SAE J518
Connection Standard: SAE J518
Role: Flange Connection
Connection Role: Flange Connection
Body & Materials

Shape: Plug
Shape Type: Flange Head Plug
Primary Material: Steel
Material Grade: 12L14/C1045
Plating: Trivalent Zinc
Dimensions

Weight: 0.30 lb
Performance Specifications

Working Pressure: 6000 psi
Temperature Range: -65°F to 500°F
Corrosion Resistance: 120 hrs no white rust; 240 hrs no red rust per ASTM B117
Burst Pressure: 24000 psi
Burst Ratio: 4:1
Cross References

Parker TFD Part Number: 12PQ2SX
Regulatory & Compliance

RoHS Compliance: Compliant by Exemption 6a-I (Lead in steel alloy)
REACH Compliance: May contain Lead ≥0.1%
Series Configuration

Code 62 Flange Plug
Technical Series Configuration

SAE J518 Code 62 Split Flange Head Plug
Side 1 Connection Type

Flange Plug
Shape

Cap/Plug
Product Type

Fittings
