D6565-L15-L10-SS

Connection Details	Side 1 Connection Type: Female Metric Swivel Side 1 Tube OD: 15mm Side 1 Thread Type: M22X1.5 Side 1 Standard: DIN 2353, ISO 8434-1 Side 1 Role: Line Connection Side 1 DIN Pressure Series: Light Side 1 Replacement Seal: M4000-15-VITON Side 2 Connection Type: Female Metric Swivel Side 2 Thread Type: M16X1.5 Side 2 Standard: DIN 2353, ISO 8434-1 Side 2 Role: Line Connection Side 2 DIN Pressure Series: Light
Body & Materials	Shape: Straight Shape Type: Swivel Reducer Union Primary Material: Stainless Steel Material Grade: 316Ti (1.4571) Seal Code: FKM Seal Material: Viton (Fluorocarbon)
Dimensions	Hex/Wrench: 27mm Weight: 0.22 lb
Performance Specifications	Working Pressure: 5802 psi Temperature Range: -15°F to 400°F Temperature Notes: Temperature limited by FKM Seal Burst Pressure: 23208 psi Burst Ratio: 4:1
Cross References	Parker TFD Part Number: GZR15/10L71
Regulatory & Compliance	RoHS Compliance: Compliant REACH Compliance: No Substance(s) Present Above Threshold
Series Configuration	DIN Tube Swivel x DIN Tube Swivel
Technical Series Configuration	DIN 2353/ISO 8434-1 Flareless Swivel Tube x Flareless Swivel Tube Reducer Union
Side 1 Connection Type	Female Metric Swivel
Side 2 Connection Type	Female Metric Swivel
Shape	Straight
Product Type	Fittings
