7403-24-24-24-NWO-SS

Connection Details	Side 1 Connection Type: Male BSPP 60° Line Only Side 1 Thread Type: G – 1-1/2-11 Side 1 Standard: ISO 8434-6 Side 1 Role: Line Connection Side 2 Connection Type: Male BSPP 60° Line Only Side 2 Thread Type: G – 1-1/2-11 Side 2 Standard: ISO 8434-6 Side 2 Role: Line Connection Side 3 Connection Type: Male BSPP Adjustable ORR Side 3 Thread Type: G – 1-1/2-11 Side 3 Standard: ISO 1179 Side 3 Role: Port Connection Side 3 Replacement Seal: 9901-24 Side 3 Replacement Washer: 9200-24-SS
Body & Materials	Shape: Tee Primary Material: Stainless Steel Material Grade: 316/316L Surface Treatment: Passivated Seal Code: NBR Seal Material: Buna-N (Nitrile)
Dimensions	Hex/Wrench: 2.165 Weight: 2.74 lb
Performance Specifications	Working Pressure: 1500 psi Temperature Range: -40°F to 250°F Temperature Notes: Temperature limited by NBR Seal Burst Pressure: 6000 psi Burst Ratio: 4:1
Regulatory & Compliance	RoHS Compliance: Compliant REACH Compliance: No Substance(s) Present Above Threshold
Series Configuration	Male BSPP x Male BSPP x Male BSPP Adjustable ORR
Technical Series Configuration	ISO 8434-6 Male BSPP Line x ISO 8434-6 Male BSPP Line x Male BSPP Adjustable Port Branch Tee
Side 1 Connection Type	Male BSPP 60° Line Only
Side 2 Connection Type	Male BSPP 60° Line Only
Shape	Tee
Product Type	Fittings
