D6602-S12-S12-S12

Connection Details	Side 1 Connection Type: DIN Tube Side 1 Tube OD: 12mm Side 1 Thread Type: M20X1.5 Side 1 Standard: DIN 2353, ISO 8434-1 Side 1 Role: Tube Connection Side 1 DIN Pressure Series: Heavy Side 2 Connection Type: Female Metric Swivel Side 2 Thread Type: M20X1.5 Side 2 Standard: DIN 2353, ISO 8434-1 Side 2 Role: Line Connection Side 2 DIN Pressure Series: Heavy Side 3 Connection Type: DIN Tube Side 3 Tube OD: 12mm Side 3 Thread Type: M20X1.5 Side 3 Standard: DIN 2353, ISO 8434-1 Side 3 Role: Tube Connection Side 3 DIN Pressure Series: Heavy
Body & Materials	Shape: Tee Shape Type: Swivel Run Tee Primary Material: Steel Material Grade: 11SMnPb30 Plating: Zinc Nickel Seal Code: NBR Seal Material: Buna-N (Nitrile)
Dimensions	Hex/Wrench: 17mm Weight: 0.49 lb
Performance Specifications	Temperature Range: -40°F to 250°F Temperature Notes: Temperature limited by NBR Seal Corrosion Resistance: 1,000 hrs no red rust per DIN ISO 9227 Burst Ratio: 4:1
Cross References	Parker TFD Part Number: EL12SCF
Regulatory & Compliance	RoHS Compliance: Compliant by Exemption 6a-I (Lead in steel alloy) REACH Compliance: May contain Lead ≥0.1%
Series Configuration	DIN Tube x DIN Tube Swivel x DIN Tube
Technical Series Configuration	DIN 2353/ISO 8434-1 Flareless Tube x Flareless Swivel Tube x Flareless Tube Run Tee
Side 1 Connection Type	DIN Tube
Side 2 Connection Type	Female Metric Swivel
Shape	Tee
Product Type	Fittings
