2608-06-06-06-FG

Connection Details	Side 1 Connection Type: Male JIC Side 1 Tube OD: 3/8" Side 1 Thread Type: 9/16-18 UNF Side 1 Standard: SAE J514 – Class 2A Thread Side 1 Role: Line/Tube Connection Side 2 Connection Type: Female NPTF Side 2 Pipe Size: 3/8" Side 2 Thread Type: 3/8-18 NPTF Side 2 Standard: SAE J476 Side 2 Role: Pipe Connection Side 3 Connection Type: Male NPTF Side 3 Pipe Size: 3/8" Side 3 Thread Type: 3/8-18 NPTF Side 3 Standard: SAE J476 Side 3 Role: Pipe Connection
Body & Materials	Shape: Tee Shape Type: Female Run Tee Primary Material: Steel Material Grade: C1045 Plating: Trivalent Zinc
Dimensions	Hex/Wrench: 0.875 Weight: 0.35 lb
Performance Specifications	Working Pressure: 4500 psi Temperature Range: -65°F to 500°F Corrosion Resistance: 120 hrs no white rust; 240 hrs no red rust per ASTM B117 Burst Pressure: 18000 psi Burst Ratio: 4:1
Cross References	Aeroquip Part Number: 203006-6-6S
Regulatory & Compliance	RoHS Compliance: Compliant REACH Compliance: No Substance(s) Present Above Threshold
Series Configuration	Male JIC x Female Pipe x Male Pipe
Technical Series Configuration	SAE J514 Male JIC Tube x SAE J476 Female NPTF x Male NPTF Run Tee
Side 1 Connection Type	Male JIC
Side 2 Connection Type	Female NPTF
Shape	Tee
Product Type	Fittings
