AL-04GR
Additional information
| General Applications | Air Tools Pneumatic and low-pressure hydraulic systems Lubricating oils, diesel fuel and antifreeze solutions Water lines for and blow-forming machines Robotic welders Chemical and paper industries Automation and machine tools |
|---|---|
| Tube | Oil-resistant synthetic rubber NBR (ARPM Class A) |
| Reinforcement | High-strength textile braid for secure fitting retention |
| Cover | Abrasion, ozone, and flame resistant NBR cover (MSHA-approved) |
| Service Temperature Range | -40°F (-40°C) to +212°F (+100°C)* -40°F (-40°C) to +160°F (+70°C) for air transfer* |
| Safety Factor | 4:1 |
| Branding | ALFAGOMMA – AUTOLOCK EVOLUTION – NON CONDUCTIVE ___ [ID Size] WP ___ PSI FLAME RESISTANT MSHA IC-152/21 – [Date Code] |
| Packaging | Reels of various lengths (see chart) Max two or three** pieces per reel (Min piece length 50') |
| Features and Advantages | Push-On Assembly: Easy to connect, no clamps or tools required. Flame Resistance: MSHA-approved cover for safety in hazardous environments (No. IC-152/21). Durable Construction: Long-lasting, resistant to wear, ozone, and hydrocarbons. Oil Resistant Tube: Meets APRM Class A (High Oil Resistance) Rating, for use with gasoline, diesel, bio-diesel and kerosene. Non-conductive Tube and Cover^: Helps protect user from shock when used near high-voltage sources. Mandrel-Built Braided Construction Quality: Stable under pressure with minimal expansion and twisting Better kink resistance and dimensional consistency Superior pressure tolerance compared to competitors Highly flexible design, works well in tight spaces |
| Packaging (per reel) | Max 3 pieces of various lengths |
| Brand | Alfagomma® |
| Type | Push-On Hose |
| Style | Braided |
| Performance | Non-Conductive Braided Construction |
| Oil Resistance | ARPM – Class A |
| Note | **Max three pieces for 1/4" through 1/2" ID, max two pieces for 5/8" through 1" ^Meets a minimum of 1,000,000 ohms per inch resistance when tested with a 1,000-volt D.C. megger. |
| Color | Green |
| ID | 1/4 in 6 mm |
| OD | 0.51 in 13 mm |
| Working Pressure | 400 psi |
| Approximate Reel Length | 600 ft |
| Packaging† (per reel) | Max 3 pieces of various lengths |
| Weight | 0.09 lbs/ft |
