Split Flange Pairs / 1951-16-M10

1951-16-M10

1951-16-M10
1951-16-M10 - Image 2
1951-16-M10 - Image 3
1951-16-M10 - Image 4
Product Code: 1951-16-m10 Brand:
Options
1951-08-m10 1951-12-m10 1951-16-m10 1951-20-m10 1951-32-m12 1951-40-m12
- +

Description

16 CD 61 Splt Flg (2)Halves, 10mm Bolt Holes

Additional information

Connection Details

Flange Interface Flange Size: 1"
Performance Specifications

Working Pressure: 5000 psi
Temperature Range: -65°F to 500°F
Burst Pressure: 20000 psi
Burst Ratio: 4:1
Cross References

Parker Hose Part Number: M1H-16 (2PCS)
Series Configuration

Code 61 Split Flange Pair w/Metric Bolt Holes
Technical Series Configuration

SAE J518 Code 61 Split Flange Pair with Metric Bolt Holes
