122HCNSS1/4 - Capital Rubber & Gasket: A Singer Industrial Company

Stainless Steel 316 Pipe Fitting, Close Nipple, Male NPT 1/4″

Connection Details	Side 1 Connection Type: Male NPT Side 1 Pipe Size: 1/4" Side 1 Thread Type: 1/4-18 NPT Side 1 Standard: ASME/ANSI B1.20.1 Side 1 Role: Pipe Connection Side 2 Connection Type: Male NPT Side 2 Pipe Size: 1/4" Side 2 Thread Type: 1/4-18 NPT Side 2 Standard: ASME/ANSI B1.20.1 Side 2 Role: Pipe Connection
Body & Materials	Shape: Straight Shape Type: Close Nipple Primary Material: Stainless Steel Material Grade: 316L Surface Treatment: Passivated Length: 1.12"
Dimensions	Overall Length/Centerline: 1.12" Weight: 0.046 lb
Performance Specifications	Temperature Range: -425°F to 1200°F
Cross References	Gal #: 3001241 Swagelok Part Number: SS-4-CN
Series Configuration	Male NPT x Male NPT
Side 1 Connection Type	Male NPT
Side 2 Connection Type	Male NPT
Product Type	Fittings
